P1 Series Overcurrent and Earth Fault Protection Relay

Send Inquiry

Request To Call Back

P1 Series Overcurrent and Earth Fault Protection Relay

Price 300000.0 INR/ Number

Get a Price/Quote

MOQ : 1 Number

P1 Series Overcurrent and Earth Fault Protection Relay Specification

Working Temperature
-10C to +55C Celsius (oC)

Coil Voltage
Does not apply (solid state relay) Volt (V)

Contact Material
Silver alloy

Power Consumption
< 6 VA Volt-Ampere (VA)

Protect Feature
Other

Contact Form
1 NO + 1 NC

Mechanical Life
Over 10 million operations Seconds

Ambient Temperature
-10C to +55C Celsius (oC)

Dielectiric Strength
2kV AC, 1 min Kilopascals (KPa)

Coil Power
Does not apply (solid state relay)

Contact Resistance
< 100 m Milliohm (m)

Product Type
Protection Relay

Insulation Resistance
> 1000 M at 500 VDC

Theory
Other

Usage
Overcurrent and Earth Fault Protection in electrical systems

Contact Load
Other

Operate Time
< 30 ms Minutes

Terminal Type
Other

Rated Voltage
110-240 VAC/DC Volt (V)

Supply Terminal
Rear plug-in type

Size

Color
Grey with blue and black front panel

Dimension (L*W*H)
130 x 106 x 140 mm Meter (m)

Weight
s ox. 1.2 kg Kilograms (kg)

Trip Output Contacts
2 changeover

Power Supply Frequency
45 to 65 Hz

Reset
Manual and electrical reset available

Compliance Standards
IEC 60255, IS 3231

Display Type
LED indicators

Communication Ports
RS485 (Modbus RTU supported)

Frequency
50/60 Hz selectable

Setting Range
0.1 to 10x In for current, 0 to 99 sec for delay

Relay Type
Numerical relay

Measuring Inputs
1-phase or 3-phase current inputs

Mounting Type
Flush or surface mounting

Programmable Features
Pick-up current and time delay adjustable

Enclosure Protection
IP54 on the front panel

Event Memory
Fault event record up to 50 events

P1 Series Overcurrent and Earth Fault Protection Relay Trade Information

Minimum Order Quantity
1 Number

Payment Terms
Cash in Advance (CID)

Supply Ability
5000 Per Month

Delivery Time
10 Days

Main Domestic Market
All India

About P1 Series Overcurrent and Earth Fault Protection Relay

P1 Series Overcurrent and Earth Fault Protection Relay-a praiseworthy addition to electrical safety! This hot deal places the spotlight on optimum protection with flush or surface mounting options and LED indicator displays. Engineered for laureate reliability, it supports 1-phase or 3-phase current inputs, features RS485 (Modbus RTU) communications, and is backed by IEC 60255 and IS 3231 compliance. With programmable pick-up and time delay, event memory up to 50 incidents, and IP54-rated front panel, MICOM PX10 ensures efficient and precise safeguarding for modern electrical systems.

Spotlight on Commercial Application & Distinct Features

The P1 Series Relay excels in demanding commercial spaces, offering advanced overcurrent and earth fault protection. Distinguished by its programmable features, event memory, and robust IP54 enclosure, it assures durability and flexibility. The laureate design accommodates professional installation across factories, substations, and commercial buildings. Its optimum event recording, quick manual/electrical reset, and compliance with major standards render it a praiseworthy solution among contemporary protection relays.

Sample Policy, Payment Terms, and Packaging Information

Sample policies for the P1 Series ensure hands-on evaluation for your facility through verified purchase order processes. We accept a range of payment terms for your convenience. Each relay is securely packaged for safe transportation and express shipping is available upon request. International and domestic clients are supported with detailed documentation, ensuring swift, damage-free delivery to your desired location.

FAQ's of MICOM PX10 Compact Overcurrent and Earth Fault Protection Relay:

Q: How do you mount the P1 Series relay in an electrical panel?

A: The MICOM PX10 relay supports both flush and surface mounting, allowing flexible installation based on the panel configuration and space availability.

Q: What are the primary commercial uses of the MICOM PX10?

A: This relay is designed for overcurrent and earth fault protection in electrical systems across industries such as factories, substations, and large commercial buildings.

Q: How can the relay's programmable pick-up current and time delay be adjusted?

A: Users can easily program the pick-up current (0.1 to 10x In) and the time delay (0 to 99 seconds) via the relay's control interface, providing customized protection settings.

Q: What standards does the P1 Series comply with for safety and performance?

A: The relay meets IEC 60255 and IS 3231 compliance standards, ensuring reliability and safety for professional electrical protection applications.

Q: When is fault data available for review in the event memory feature?

A: The event memory allows users to view records of up to 50 fault incidents, which are logged and accessible anytime via the relay's interface for diagnostics and maintenance.

Q: Where can customers request express shipping for the P1 Series?

A: Express shipping is available upon request for both national and international customers when placing a purchase order with the supplier or trader.
